技术参数:
额定电流: 1.0 A
接触电阻: 30mΩ Max
绝缘电阻: 1000MΩ Min
耐压值 : 300V AC/minute
工作温度: -40℃ to +105℃
1.27mm单塑排针(单,双排);SMT
SPECIFICATIONS(技术参数):
Current Rating(额定电流): 1.0 A
Contact Resistance(接触电阻): 30mΩ Max
Insulation Resistance(绝缘电阻): 1000MΩ Min
Withstand Voltage(耐压值): 300V AC/minute
Operation Temperature(工作温度): -40°C to +105°C
MATERIALS(材质):
Contact Material(接触件材质): Copper Alloy
Contact Plating(接触件电镀): Gold or Tin over 50u' Ni
Insulator Material(绝缘体材质):Nylon-6T
![](/data/editor/attached/image/20210524/20210524160010_84143.png)
